View In:   ArcGIS Online Map Viewer

Name: Stormwater Basin

Display Field: pwname

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: City of Blaine's stormwater management basin polygons. These basin polygons are being used for visual awareness, spatial representation, and for various analysis needs within the city of Blaine. These features are updated on a as needed basis. Last update September 2020.

Service Item Id: 02f8e5e0b79b41fd9709e4430f1f97e0

Copyright Text: City of Blaine GIS Department City of Blaine Engineering Department City of Blaine Public Works Department Contract services retained with the city of Blaine.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 499705.04017739
YMin: 130784.69300746918
XMax: 531969.091134727
YMax: 164183.2397273034
Spatial Reference: 0  (0)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [191, 217, 242, 255]
Outline:
N/A
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: true
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• objectid ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• asset_id ( type: esriFieldTypeString, alias: Asset ID, editable: false, nullable: true, length: 32, defaultValue: null, modelName: asset_id )
• lifecycle_status ( type: esriFieldTypeString, alias: Lifecycle Status, editable: true, nullable: true, length: 50, defaultValue: Active, modelName: lifecycle_status , Coded Values: [Not Built: Not Built] , [Planned: Planned] , [Proposed: Proposed] , ...4 more... )
• owner ( type: esriFieldTypeString, alias: Owner, editable: true, nullable: true, length: 75, defaultValue: City of Blaine, modelName: owner , Coded Values: [Anoka County: Anoka County] , [City of Andover: City of Andover] , [City of Blaine: City of Blaine] , ...16 more... )
• maintainer ( type: esriFieldTypeString, alias: Maintainer, editable: true, nullable: true, length: 255, defaultValue: City of Blaine, modelName: maintainer , Coded Values: [Anoka County: Anoka County] , [City of Andover: City of Andover] , [City of Blaine: City of Blaine] , ...16 more... )
• local_type ( type: esriFieldTypeString, alias: Local Type, editable: true, nullable: true, length: 40, defaultValue: null, modelName: local_type )
• water_body_function ( type: esriFieldTypeString, alias: Water Body Function, editable: true, nullable: true, length: 255, defaultValue: null, modelName: water_body_function )
• parent_asset_id ( type: esriFieldTypeString, alias: Parent Asset ID, editable: true, nullable: true, length: 40, defaultValue: null, modelName: parent_asset_id )
• local_surv_name ( type: esriFieldTypeString, alias: Local Survey Name, editable: true, nullable: true, length: 150, defaultValue: null, modelName: local_surv_name )
• name ( type: esriFieldTypeString, alias: Name, editable: true, nullable: true, length: 150, defaultValue: null, modelName: name )
• ms4_inspection_area ( type: esriFieldTypeSmallInteger, alias: MS4 Inspection Area, editable: false, nullable: true, defaultValue: null, modelName: ms4_inspection_area , Range: [1, 5] )
• drain_tile ( type: esriFieldTypeString, alias: Drain Tile (Y/N), editable: true, nullable: true, length: 5, defaultValue: null, modelName: drain_tile )
• inf_bench_shelf ( type: esriFieldTypeString, alias: Infil. Bench/Shelf, editable: true, nullable: true, length: 10, defaultValue: null, modelName: inf_bench_shelf )
• local_restrictions ( type: esriFieldTypeString, alias: Local Restrictions, editable: true, nullable: true, length: 50, defaultValue: null, modelName: local_restrictions )
• basn_dnrid ( type: esriFieldTypeString, alias: DNR Lake ID, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basn_dnrid )
• basn_type ( type: esriFieldTypeString, alias: Basin Type, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basn_type )
• basn_depth ( type: esriFieldTypeDouble, alias: Basin Depth, editable: true, nullable: true, defaultValue: null, modelName: basn_depth )
• basn_vld ( type: esriFieldTypeDouble, alias: Basin Design Volume, editable: true, nullable: true, defaultValue: null, modelName: basn_vld )
• basn_nelv ( type: esriFieldTypeDouble, alias: Basin Normal Elevation, editable: true, nullable: true, defaultValue: null, modelName: basn_nelv )
• basn_felv ( type: esriFieldTypeDouble, alias: Basin Flood Stage Elevation, editable: true, nullable: true, defaultValue: null, modelName: basn_felv )
• basn_belv ( type: esriFieldTypeDouble, alias: Basin Designed Bottom Elevation, editable: true, nullable: true, defaultValue: null, modelName: basn_belv )
• basn_oelv ( type: esriFieldTypeDouble, alias: Basin Overflow Elevation, editable: true, nullable: true, defaultValue: null, modelName: basn_oelv )
• basn_ohwl ( type: esriFieldTypeDouble, alias: Basin Ordinary High Water Level, editable: true, nullable: true, defaultValue: null, modelName: basn_ohwl )
• basn_orig ( type: esriFieldTypeString, alias: Constructed or Natural Origin, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basn_orig )
• basn_303d ( type: esriFieldTypeString, alias: Basin 303(d) Impairment Status, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basn_303d )
• basnabdoc ( type: esriFieldTypeString, alias: As-Built Drawing Document, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basnabdoc )
• basn_easm ( type: esriFieldTypeString, alias: Basin Easement, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basn_easm )
• basn_datan ( type: esriFieldTypeString, alias: Basin Producer/Source Name, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basn_datan )
• basn_dasrc ( type: esriFieldTypeString, alias: Basin Data Source, editable: true, nullable: true, length: 255, defaultValue: null, modelName: basn_dasrc , Coded Values: [Anoka County: Anoka County] , [City of Andover: City of Andover] , [City of Blaine: City of Blaine] , ...16 more... )
• ctu_name ( type: esriFieldTypeString, alias: CTU Name, editable: true, nullable: true, length: 255, defaultValue: Blaine, modelName: ctu_name , Coded Values: [Aastad Township: Aastad Township] , [Acoma Township: Acoma Township] , [Acton Township: Acton Township] , ...2538 more... )
• ctu_id_txt ( type: esriFieldTypeString, alias: CTU Code, editable: true, nullable: true, length: 255, defaultValue: 02394183, modelName: ctu_id_txt , Coded Values: [00663375: Aastad Township] , [00663376: Acoma Township] , [00663377: Acton Township] , ...2634 more... )
• co_code ( type: esriFieldTypeString, alias: County Code, editable: true, nullable: true, length: 255, defaultValue: null, modelName: co_code , Coded Values: [OOJ: Out of Jurisdiction] , [27001: Aitkin] , [27003: Anoka] , ...118 more... )
• co_name ( type: esriFieldTypeString, alias: County Name, editable: true, nullable: true, length: 255, defaultValue: null, modelName: co_name , Coded Values: [OOJ: Out of Jurisdiction] , [Aitkin: Aitkin] , [Allamakee: Allamakee] , ...113 more... )
• state_code ( type: esriFieldTypeString, alias: State Code, editable: true, nullable: true, length: 255, defaultValue: MN, modelName: state_code , Coded Values: [IA: Iowa] , [MN: Minnesota] , [ND: North Dakota] , ...2 more... )
• inlet_count ( type: esriFieldTypeInteger, alias: Inlet Count, editable: true, nullable: true, defaultValue: null, modelName: inlet_count )
• outlet_count ( type: esriFieldTypeInteger, alias: Outlet Count, editable: true, nullable: true, defaultValue: null, modelName: outlet_count )
• halfsection ( type: esriFieldTypeString, alias: Half Section, editable: true, nullable: true, length: 255, defaultValue: null, modelName: halfsection )
• pagenumber ( type: esriFieldTypeSmallInteger, alias: Page Number, editable: true, nullable: true, defaultValue: null, modelName: pagenumber )
• note ( type: esriFieldTypeString, alias: Note, editable: true, nullable: true, length: 500, defaultValue: null, modelName: note )
• fulcrum_id ( type: esriFieldTypeString, alias: Fulcrum ID, editable: true, nullable: true, length: 255, defaultValue: null, modelName: fulcrum_id )
• blaine_id ( type: esriFieldTypeString, alias: Blaine ID, editable: true, nullable: true, length: 255, defaultValue: null, modelName: blaine_id )
• pwname ( type: esriFieldTypeString, alias: PWName 1, editable: true, nullable: true, length: 64, defaultValue: null, modelName: pwname )
• pwname2 ( type: esriFieldTypeString, alias: PWName 2 - questionable, editable: true, nullable: true, length: 255, defaultValue: null, modelName: pwname2 )
• created_user ( type: esriFieldTypeString, alias: created_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: created_user )
• created_date ( type: esriFieldTypeDate, alias: created_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: created_date )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: last_edited_user )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: last_edited_date )
• globalid ( type: esriFieldTypeGlobalID, alias: globalid, editable: false, nullable: false, length: 38, defaultValue: null, modelName: globalid )
• Shape__Area ( type: esriFieldTypeDouble, alias: st_area(shape), editable: false, nullable: true, defaultValue: null, modelName: st_area(shape), required: true )
• Shape__Length ( type: esriFieldTypeDouble, alias: st_perimeter(shape), editable: false, nullable: true, defaultValue: null, modelName: st_perimeter(shape), required: true )
• date_installed ( type: esriFieldTypeDate, alias: date_installed_converted, editable: true, nullable: true, length: 8, defaultValue: null, modelName: date_installed )
• date_retired ( type: esriFieldTypeDate, alias: date_retired_converted, editable: true, nullable: true, length: 8, defaultValue: null, modelName: date_retired )
• mowing_frequency_yrs ( type: esriFieldTypeDouble, alias: Mowing Frequency (years), editable: true, nullable: true, defaultValue: null, modelName: mowing_frequency_yrs )

Templates:

• Name: Stormwater Basins poly
  Description:
  Prototype:
  date_retired: null
  date_installed: null
  lifecycle_status: Active
  owner: City of Blaine
  maintainer: City of Blaine
  local_type: null
  water_body_function: null
  parent_asset_id: null
  local_surv_name: null
  name: null
  mowing_frequency_yrs: null
  drain_tile: null
  inf_bench_shelf: null
  local_restrictions: null
  basn_dnrid: null
  basn_type: null
  basn_depth: null
  basn_vld: null
  basn_nelv: null
  basn_felv: null
  basn_belv: null
  basn_oelv: null
  basn_ohwl: null
  basn_orig: null
  basn_303d: null
  basnabdoc: null
  basn_easm: null
  basn_datan: null
  basn_dasrc: null
  ctu_name: Blaine
  ctu_id_txt: 02394183
  co_code: null
  co_name: null
  state_code: MN
  inlet_count: null
  outlet_count: null
  halfsection: null
  pagenumber: null
  note: null
  fulcrum_id: null
  blaine_id: null
  pwname: null
  pwname2: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query,Sync,Extract

Sync Can Return Changes: true

Is Data Versioned: true

Supports Rollback On Failure: false

Supports ApplyEdits With Global Ids: false

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: true

Supports Coordinates Quantization: true

Child Resources:   Field Groups   Contingent Values

Supported Operations:   Query   Query Analytic   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata   Update Metadata
