Name: Stormwater Basin

Display Field: pwname

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: City of Blaine's stormwater management basin polygons. These basin polygons are being used for visual awareness, spatial representation, and for various analysis needs within the city of Blaine.

Service Item Id: 4366e46faf89403b99fb351c8d1cda48

Copyright Text: City of Blaine

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 499705.04017739
YMin: 130784.69300746918
XMax: 531969.091134727
YMax: 164183.2397273034
Spatial Reference: 0  (0)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [191, 217, 242, 255]
Outline:
N/A
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• objectid ( type: esriFieldTypeOID, alias: OBJECTID )
• asset_id ( type: esriFieldTypeString, alias: Asset ID, length: 32 )
• lifecycle_status ( type: esriFieldTypeString, alias: Lifecycle Status, length: 50 , Coded Values: [Not Built: Not Built] , [Planned: Planned] , [Proposed: Proposed] , ...4 more... )
• name ( type: esriFieldTypeString, alias: Name, length: 150 )
• local_type ( type: esriFieldTypeString, alias: Local Type, length: 40 )
• local_surv_name ( type: esriFieldTypeString, alias: Local Survey Name, length: 150 )
• basn_type ( type: esriFieldTypeString, alias: Basin Type, length: 255 )
• inlet_count ( type: esriFieldTypeInteger, alias: Inlet Count )
• outlet_count ( type: esriFieldTypeInteger, alias: Outlet Count )
• basn_depth ( type: esriFieldTypeDouble, alias: Basin Depth )
• basn_vld ( type: esriFieldTypeDouble, alias: Basin Design Volume )
• basn_nelv ( type: esriFieldTypeDouble, alias: Basin Normal Elevation )
• basn_felv ( type: esriFieldTypeDouble, alias: Basin Flood Stage Elevation )
• basn_belv ( type: esriFieldTypeDouble, alias: Basin Designed Bottom Elevation )
• basn_oelv ( type: esriFieldTypeDouble, alias: Basin Overflow Elevation )
• basn_ohwl ( type: esriFieldTypeDouble, alias: Basin Ordinary High Water Level )
• drain_tile ( type: esriFieldTypeString, alias: Drain Tile (Y/N), length: 5 )
• inf_bench_shelf ( type: esriFieldTypeString, alias: Infil. Bench/Shelf, length: 10 )
• local_restrictions ( type: esriFieldTypeString, alias: Local Restrictions, length: 50 )
• water_body_function ( type: esriFieldTypeString, alias: Water Body Function, length: 255 )
• basn_orig ( type: esriFieldTypeString, alias: Constructed or Natural Origin, length: 255 )
• basn_303d ( type: esriFieldTypeString, alias: Basin 303(d) Impairment Status, length: 255 )
• basn_easm ( type: esriFieldTypeString, alias: Basin Easement, length: 255 )
• mowing_frequency_yrs ( type: esriFieldTypeDouble, alias: Mowing Frequency (years) )
• date_installed ( type: esriFieldTypeDate, alias: date_installed_converted, length: 8 )
• date_retired ( type: esriFieldTypeDate, alias: date_retired_converted, length: 8 )
• ms4_inspection_area ( type: esriFieldTypeSmallInteger, alias: MS4 Inspection Area , Range: [1, 5] )
• owner ( type: esriFieldTypeString, alias: Owner, length: 75 , Coded Values: [Anoka County: Anoka County] , [City of Andover: City of Andover] , [City of Blaine: City of Blaine] , ...16 more... )
• maintainer ( type: esriFieldTypeString, alias: Maintainer, length: 255 , Coded Values: [Anoka County: Anoka County] , [City of Andover: City of Andover] , [City of Blaine: City of Blaine] , ...16 more... )
• basn_datan ( type: esriFieldTypeString, alias: Basin Producer/Source Name, length: 255 )
• basn_dasrc ( type: esriFieldTypeString, alias: Basin Data Source, length: 255 , Coded Values: [Anoka County: Anoka County] , [City of Andover: City of Andover] , [City of Blaine: City of Blaine] , ...16 more... )
• ctu_name ( type: esriFieldTypeString, alias: CTU Name, length: 255 , Coded Values: [Anoka: Anoka] , [Ramsey: Ramsey] )
• ctu_id_txt ( type: esriFieldTypeString, alias: CTU Code, length: 255 , Coded Values: [02393954: Andover] , [02394183: Blaine] , [02393526: Circle Pines] , ...8 more... )
• co_code ( type: esriFieldTypeString, alias: County Code, length: 255 , Coded Values: [27003: Anoka] , [27123: Ramsey] )
• co_name ( type: esriFieldTypeString, alias: County Name, length: 255 , Coded Values: [Anoka: Anoka] , [Ramsey: Ramsey] )
• state_code ( type: esriFieldTypeString, alias: State Code, length: 255 , Coded Values: [IA: Iowa] , [MN: Minnesota] , [ND: North Dakota] , ...2 more... )
• halfsection ( type: esriFieldTypeString, alias: Half Section, length: 255 )
• pagenumber ( type: esriFieldTypeSmallInteger, alias: Page Number )
• basnabdoc ( type: esriFieldTypeString, alias: As-Built Drawing Document, length: 255 )
• note ( type: esriFieldTypeString, alias: Note, length: 500 )
• basn_dnrid ( type: esriFieldTypeString, alias: DNR Lake ID, length: 255 )
• parent_asset_id ( type: esriFieldTypeString, alias: Parent Asset ID, length: 40 )
• fulcrum_id ( type: esriFieldTypeString, alias: Fulcrum ID, length: 255 )
• blaine_id ( type: esriFieldTypeString, alias: Blaine ID, length: 255 )
• pwname ( type: esriFieldTypeString, alias: PWName 1, length: 64 )
• pwname2 ( type: esriFieldTypeString, alias: PWName 2 - questionable, length: 255 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• globalid ( type: esriFieldTypeGlobalID, alias: globalid, length: 38 )
• shape ( type: esriFieldTypeGeometry, alias: shape )
• st_area(shape) ( type: esriFieldTypeDouble, alias: st_area(shape) )
• st_length(shape) ( type: esriFieldTypeDouble, alias: st_length(shape) )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
